D-Link
DGS-1100-08V2 8-port Smart Administerable Gigabit switch
DGS-1100-08V2 8-port Smart Administerable Gigabit switch
Regular price
€109,99 EUR
Regular price
€124,99 EUR
Sale price
€109,99 EUR
Unit price
/
per
Taxes included.
Shipping calculated at checkout.
Couldn't load pickup availability
DGS-1100-08V2
The DGS-1100 Series offers Smart Managed Gigabit Switches.
- 8 x 1000Base-T ports
- Fanless design
- Simple Layer 2 management
- Web-based user interface
- Limited lifetime warranty upon registration
Web Interface
User-friendly web interface for easy access to management features.
VLAN
Segment your network into VLANs.
Easy Deployment with Auto-Configuration
Simply connect the switch to your network, and it will automatically detect devices for easy management.
Energy-Efficient Design
Automatic energy-saving features reduce power consumption.
Uncomplicated. Simple. Smart.
The DGS-1100 series smart switches provide an affordable solution for environments needing straightforward network management.
Smart Web Interface
The DGS-1100's web interface allows easy management of L2 features such as VLAN, Spanning Tree Protocol (STP), and static link aggregation. Robust security features like IGMP snooping, Static MAC, and Storm Control make the DGS-1100 series a versatile solution for environments requiring hassle-free deployment and configuration.
Free Network Management Software
Download our free Nuclias Connect software designed for network integrity, control, and cost-effective scaling. It can be used as a local software management platform or a cloud solution. Alternatively, the dedicated Nuclias Connect Hub provides hardware-based centralized network management.
Easy Troubleshooting
The DGS-1100 series includes loopback detection and cable diagnostics to help network administrators quickly and easily identify and resolve network issues.
Loopback detection identifies loops created by a specific port and automatically disables the affected port. The cable diagnostics feature is designed for network administrators to quickly assess copper cable quality, identify cable types, and detect cable faults.
Green Technology
The DGS-1100 series incorporates energy-saving features without compromising performance. Most switches in the series have a fanless design for quiet and energy-efficient operation. All are IEEE 802.3az compliant and include Link Status detection and Time-Based PoE (except for models DGS-1100-05PD and DGS-1100-08P).
Free Next Business Day Service
Standard service includes free next business day replacement for faulty equipment. Our rapid technical support is designed to provide businesses with optimal support for their unique environments. Our extended warranty and service packages further increase warranty periods and minimize downtime.
Specifications
General
Form Factor: Desktop
Number of Ports: 8 x 10/100/1000 Mbps
Port Features: IEEE 802.3 for Ethernet, IEEE 802.3u for Fast Ethernet, IEEE 802.3ab for Gigabit Ethernet, Auto Negotiation, Half/Full-Duplex Support (Half at 10/100 Mbps, Full at 1000 Mbps), Auto MDI/MDIX, IEEE 802.3x Flow Control supports full-duplex mode, IEEE 802.3az compliant
Performance
Switching Capacity: 16 Gbps
Maximum Forwarding Rate: 11.9 Mpps
MAC Address Table Size: 4K entries
Packet Buffer: 1.5 Mbits
Flash Memory: 2 Mbytes
Power Consumption
Standby Mode: 1.93 W
Maximum Power Consumption: 4.94 W
Physical
Power Supply: 100 to 240 V AC, 50 to 60 Hz external power adapter
MTBF: 1,456,992 hours
Acoustics: 0 dB(A)
Heat Dissipation: 16.85 BTU/hour
Weight: 0.34 kg
Dimensions: 145 x 82 x 28 mm
